경량화와 강성이 필요한 광범위한 분야에 적용되는 첨단소재 직물입니다. 전도성이 있으며, 낚시대 골프채등 레져 산업부터 항공기 동체 및 우주산업, 군사장비까지 점점 적용 분야가 넓어지고 있습니다. 1K에서 50K까지 다양한 필라멘트 가닥수를 이용하여 가볍고 촘촘한 직물부터 거대한 풍력발전 블레이드에 적합한 직물까지 다양한 용도에 평직, 능직, 주자직, 일방향 직물등 다양한 패턴을 선보이고 있습니다.  아울러 엔트라코리와 TEI는 가전과 자동차, 패션등에 일반 산업용을 뛰어넘는 생활에 필요한 디자인들을 개발하기 위해, 새로운 실험과 지속적인 혁신으로 보다 다양한 제품군을 새로이 선보이고 있습니다.


1K Carbon Fiber Fabrics

The smallest and tightest weave available,only the most specialized composite weavers have the skill and technique to produce this intricate material. Most commonly used in the sports,apparel and industries such as precision watch manufacturing,where carbon is utilized on a small scale,to allow for fine details and intricate surface areas.Available in Plain or Twill weave.
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-1101 Plain 1000 22.5 22.5 0.16 125 110 /
TI-1601 Twill 1000 24 25 0.15 130 110 /


3K Carbon Fiber Fabrics

The most commonly used composite fabric,with applications in all areas of industry,from household appliances to robotics and other high-spec industries including aerospace. TEI has the technical know-how to produce 3K Carbon in 4 different weave patterns,perfect for every application. Regular weave,Twill,4HS satin and 8HS satin.
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-3101 Plain 1020 12.5 12.5 0.2 200 100 /
TI-3101-A Plain 1020 12.5 12.5 0.2 200 100 One Side Silver Plated
TI-3101-AA Plain 1020 12.5 12.5 0.2 200 100 Two Sides Silver Plated
TI-3101-S Plain 1020 13 13 0.2 205 100 Immoveable
TI-3107 Plain 1020 13 13 0.2 210 100 /
TI-3107-A Plain 1020 13 13 0.2 210 100 One Side Silver Plated
TI-3108 Plain 1500 13 13 0.2 210 100 /
TI-3150 Plain 1270 12.5 12.5 0.2 208 100 /
TI-3151 Plain 1270 13 13 0.2 210 100 /
TI-3151-S Plain 1270 13 13 0.2 208 100 Immoveable
TI-3165-S Plain 1650 13 13 0.2 212 50 For Car Industry / Immovable treatment
TI-3201 Plain 1020 15 15 0.24 240 100 /
TI-3201-A Plain 1020 15 15 0.24 240 100 One Side Silver Plated
TI-3205 Plain 1020 15 15 0.24 242 100 /
TI-3301 Plain 1020 10 10 0.16 160 100 /
TI-34401 Twill 4x4 1020 17 13 0.2 240 100
TI-3601 Twill 1020 13 13 0.2 208 100 /
TI-3601-S Twill 1020 13 13 0.2 205 100 Immoveable
TI-3611 Twill 1020 15 15 0.24 240 100 /
TI-3611-A Twill 1020 15 15 0.24 240 100 One Side Silver Plated
TI-3617-A Twill 1020 13 13 0.21 210 100 One Side Silver Plated
TI-3665-S Twill 1650 13 13 0.2 212 50 For Car Industry / Immovable treatment
TI-3711 Twill 1270 13 13 0.2 210 100 /
TI-3711-S Twill 1270 13 13 0.2 208 100 Immoveable
TI-3811 Twill 1500 13 13 0.2 210 100 /
TI-3824 8HS 1020 24 24 0.5 384 100 /
TI-3951 5HS 1020 18 18 0.35 282 100 /
TI-3952 5HS 1020 20 20 0.45 320 100 /


6K Carbon Fiber Fabrics

The workhorse of Carbon Fiber,6K weave is perfectly suited for structural applications due to its resistance to flex,but is light enough to be able to contour to complex shapes and angles with no problems and weave distortion. Available in Plain,Twill and 4HS(Satin weave)
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-6101 Plain 1020 10 10 0.32 320 100 /
TI-6108 Twill 1020 10 10 0.32 320 100 /
TI-6201 Plain 1020 12 12 0.4 410 50 /
TI-6601 Twill 1020 9.5 9.5 0.3 305 100
TI-6941 4HS 1020 12 12 0.45 370 100 /
TI-6948 8HS 1020 15 15 0.45 475 100


12K Carbon Fiber Fabrics

This heavy duty fabric is best suited to flat panels or where structural rigidity is a must(construction,marine) or for reinforcement for lighter weight material. TEI has 12K Carbon Fiber in Plain,Twill,UD and Hybrid,giving you all options for your production requirements
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-12101 Plain 1020 8 8 0.55 520 50 /
TI-12105 Plain 1020 9 9.5 0.6 600 50 /
TI-12201 12K Plain 1020 10 10 0.65 650 50 /
TI-12601 12K Twill 1020 10 10 0.7 610 50 /
TI-12633 Twill 1020 13 13 0.9 840 50 /
TI-12680 8HS 1020 10 10 0.65 680 50


24K Carbon Fiber Fabrics

Lightness weight, higher strength, higher rigidity, lower fatigue. the application for modelling, motor sports, aircraft construction, ship construction, sports equipment, automotive engineering and other carbon design tagged applications. Plain, Twill and Hybrid.
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-24101 Plain 1020 6 6 0.7 680 50 /
TI-24201 Plain 1020 8 8 0.9 900 50 /
TI-24601 Twill 1020 6 6 0.7 680 50 /
TI-24602 Twill 1020 9 9 1.1 1120 50 /


Glitter Carbon Fiber Fabrics

The most commonly used composite fabric, but now you have another choice with colored Glitter fiber. TEI has the technical know-how to produce special Carbon series with colored glitter fiber; Carbon fiber will not be just black.
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TEI-301 UD 1020 0 0 0.2 305 100 Silver
TEI-302 UD 1020 0 0 0.2 305 100 Gold
TEI-303 UD 1020 0 0 0.2 305 100 Blue
TEI-305 UD 1020 0 0 0.2 305 100 Green
TEI-307 UD 1020 0 0 0.2 305 100 Red
TI-301 Plain 1020 13 13 0.2 210 100 Silver
TI-302 Plain 1020 13 13 0.2 210 100 Golden
TI-302-2 plain 1020 13 13 0.21 220 100 1mm, Golden, heat protection
TI-303 Plain 1020 13 13 0.2 210 100 Blue
TI-303-3 Plain 1020 13 13 0.21 220 100 1mm, Blue, heat protection
TI-305 Plain 1020 13 13 0.2 210 100 Green
TI-305-5 Plain 1020 13 13 0.21 220 100 1mm, Green, heat protection
TI-307 Plain 1020 13 13 0.2 210 100 Red
TI-307-7 Plain 1020 13 13 0.21 220 100 1mm, Red, heat protection
TI-308-8 Plain 1020 13 13 0.21 220 100 1mm, Purple , heat protection
TI-311 Plain 1020 13.5 13.5 0.2 210 100 Think Sliver yarn
TI-312 Plain 1020 13.5 13.5 0.2 210 100 Think Golden yarn
TI-313 Plain 1020 13 13 0.2 210 100 50% Blue Aramid, Silver
TI-321 Plain 1020 13 13 0.25 250 100 50% Glass, Silver
TI-322 Plain 1020 13 13 0.25 250 100 50% Glass, Golden
TI-323 Plain 1020 13 13 0.25 250 100 50% Glass, Blue
TI-325 Plain 1020 13 13 0.25 250 100 50% Glass, Green
TI-327 Plain 1020 13 13 0.25 250 100 50% Glass, Red
TI-341 Plain 1020, 1270 13 13 0.2 200 100 Uni-Silver
TI-3411 Plain 1020, 1270 13 13 0.2 200 100 Bi-Silver
TI-3413 Plain 1020, 1270 13 13 0.2 200 100 Bi-Silver x Blue
TI-3415 Plain 1020, 1270 13 13 0.2 200 100 Bi-Silver x Green
TI-3417 Plain 1020, 1270 13 13 0.2 200 100 Bi-Silver x Red
TI-3418 Plain 1020, 1270 13 13 0.2 200 100 Bi-Silver x Purple
TI-342 Plain 1020, 1270 13 13 0.2 200 100 Uni-Gold
TI-3423 Plain 1020, 1270 13 13 0.2 200 100 Bi-Gold x Blue
TI-3425 Plain 1020 13 13 0.2 200 100 Bi-Gold x Green
TI-3428 Plain 1020 13 13 0.2 200 100 Bi-Gold x Purple
TI-3478 Plain 1020 13 13 0.2 200 100 Bi-Red x Purple


Glitter Carbon Jacquard Fabrics

Making a new style for your selection. Colored glitter makes the Carbon fiber more colorful, but we also present you several different jacquard styles.
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-3871 Jacquard 1020 17 17 0.4 205 100 Silver
TI-3872 Jacqard 1020 17 17 0.4 205 100 Gold
TI-3873 Jacqard 1020 17 17 0.4 205 100 Blue
TI-3873-1 Jacqard 1020 17 17 0.4 205 100 Pale Blue
TI-3874 Jacqard 1020 17 17 0.4 205 100 Black
TI-3875 Jacqard 1020 17 17 0.4 205 100 Green
TI-3877 Jacqard 1020 17 17 0.4 205 100 Red
TI-3878 Jacqard 1020 17 17 0.4 205 100 Purple
TI-3879 Jacqard 1020 17 17 0.4 205 100 Bronze


Carbon Jacquard Style Woven

With the wonderful ideas, TEI presents you new style Carbon woven, you could select the new style to enrich your products..
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-3171 Jacquard 1020 17 17 0.25 272 100 100% 3K Carbon
TI-38121 Jacquard 1020 17 17 0.22 272 100 Hexangular 3K
TI-38151 Jacquard 1020 17 17 0.22 272 100 Rhombus 3K
TI-38161 Jacquard 1020 17 17 0.22 272 100 Arrow 3K


Metallic Carbon Jacquard Fabrics

The metallic materials with Carbon materilas.
Code No. Weaving
Methods		 Width Constrution
(25m/m)		 Thickness Weight Roll length Weave
m/m Warp Fill m/m g/m2 M
TI-34403 Twill 4x4 1020 17 13 0.2 270 100 3K x Blue
TI-34403-1 Twill 4x4 1020 17 13 0.2 270 100 3K x Pale Blue
TI-34405 Twill 4x4 1020 17 13 0.2 270 100 3K x Green
TI-34407 Twill 4x4 1020 17 13 0.2 270 100 3K x Red
TI-34408 Twill 4x4 1020 17 13 0.2 270 100 3K x Purple
TI-34409 Twill 4x4 1020 17 13 0.2 270 100 3K x Bronze
TI-34411 Twill 4x4 1020 17 13 0.2 270 100 3K x Silver
TI-3871-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Silver Cooper
TI-3871-Ni Jacquard 1020 17 17 0.4 205 100 Silver Titanium
TI-3872-1-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Gold Cooper
TI-3872-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Natural Copper
TI-3873-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Blue Cooper
TI-3874-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Black Cooper
TI-3875-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Green Cooper
TI-3877-1-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Pink Cooper
TI-3877-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Red Cooper
TI-3878-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Purple Cooper
TI-3879-CU Jacquard 1020 17 17 0.5 442 100 Carbon x Brown Cooper
